BELTUZA

BELTUZA

Satake BELTUZA® belt sorter provides continuous inspection to ensure the highest quality product, removing unwanted foreign material, discolorations and misshapen product, maintaining maximum yield.

Featuring full colour RGB cameras & Shape Recognition technology, abnormal shapes, broken and connected product can be sorted, minimising damage to the product that could be caused by mechanical separation.

  • Full colour RGB cameras and Shape Recognition technology
  • Belt stably and uniformly conveys the materials
  • Detachable components for easy maintenance, cleaning and connection flexibility
  • Now also available with Infrared technology

The belt stably and uniformly conveys the materials to assure high sorting accuracy and the improved LED lighting enables the sensors to capture the slightest colour differences. Defective products are ejected from the product stream by air.

Detachable components such as vibratory feeders provide easy maintenance, cleaning and flexibility to connect directly to an existing production line if desired.

Feeding and discharging sections are made of stainless steel for higher hygiene standards.

BELTUZA’s lower belt speed can handle a wider range of lighter products than previous models

BELTUZA XeNO – With InGaAs Infrared Technology

Full colour RGB cameras detect colour and shape defects, while Infrared camera detects inorganic foreign material such as stone, plastics, and glasses that have similar colour as accept product.

Another technological advantage present in all Satake Colour Sorting machines is their ability to automatically recalibrate without production stoppage.

Product Advantages

  • InGaAs Infrared Technology for removing inorganic and foreign material
  • Full colour for subtle colour differences
  • Belt and Vibratory design minimises product damage
  • Minimal operator training required
  • Quick and easy product & defect set-up
  • Easy cleaning and maintenance
  • Automatic sorting parameter function
  • One touch pre-set recall
  • No changeover parts between products
  • Long-life LED lighting
  • No downtime for calibration
  • Quick return of investment

Product Features

  •  InGaAs Infrared Technology
  • Full colour RGB camera technology
  • 3D colour map technology
  • Shape and size sorting capability
  • Removable vibratory feeder system
  • Accept product impact-reduction design
  • Wide belt with lightweight contamination cover
  • Separable body design for quick belt change
  • Stainless steel body construction
  • Automatic Smart Sensitivity System
  • Multilingual touch screen and user friendly interface and image capture technology
  • Choice of various LED lighting options to perfectly suit the application
  • High speed, digital signal processing tech­nology
  • Large smart touch screen panel

Machine Overview

Peanuts

Pet Food

Optical Sorting Solutions for all applications
